Spline Drive Air Compressors - SAE A, B & C Direct Drive Compressors

100% Duty Cycle

20-70 CFM. 100% of the time.

Compact Size

Built to fit in tight spaces. 25% smaller than competitive products. 654 in³ (10.7 L) vs. competitor’s 877 in³ (14.4 L).

Lightweight, Aluminum Design

60% weight savings compared to competitive products. 28 lb (12.7 kg) vs. competitor’s 68 lb (31 kg).

SAE PTO Port Driven

SAE A, B & C port/spline configurations available.

6X More Output

In a package that is 25% smaller and 60% lighter than leading reciprocating competitors.

Single Gear Spline Drive Specifications

Min. Working Pressure

90 psi

6.2 bar

Max. Working Pressure

175 psi

12.0 bar

Maximum Air Output*

70 CFM

1,982 l/min

Compressor Weight

28 lb

12.7 kg

Gear Ratio

3.21:1

Rotation

Clockwise

Maximum Shaft Speed

3,600 RPM

*Using ASME PTC 19.5 – 2004 flow measurement standard at 100 psi
