Gas Powered Air Compressors

Overview

VMAC G30 gas powered air compressors are the best choice for customers that need the lightweight, compact performance of a rotary screw air compressor, at the lowest price possible.

btn

Jan2018 - HEG

Applications – Common jobs that use the compressor system:

  • Light/medium duty mobile mechanics
  • Mobile tire service technicians
  • Light duty contractors

Commonly used tools:

  • 3/4” impact wrenches
    • Up to 1″ impact wrench with a small air receiver tank
  • Backfill tampers
  • 2” Horizontal grinders
  • Chipping hammers
  • Die grinders
  • Tire inflation
  • Air wands/blow guns

Benefits

30 CFM. 100% of the Time.

VMAC G30 gas powered air compressors include a patented 30 CFM rotary screw air compressor designed to produce full air power, 100% of the time, so you don’t need an air receiver tank. Get jobs done faster, without interruption.

60% Lighter

VMAC G30 gas powered air compressors are engineered and manufactured for mobile applications. Weighing only 205 lb, the VMAC G30 is up to 60% lighter than typical 22 – 30 CFM reciprocating gas engine driven air compressors with 30-gallon air receiver tank. Choosing a lightweight air compressor means you’ll be able to add more tools and equipment to your truck, carry more materials, or take advantage of better fuel economy.

50% Smaller

VMAC air compressors feature the latest rotary screw technology integrated into a compact, turn-key package that is over 50% smaller than other competitive models. You can fit more tools, equipment and supplies on your truck, without hassle.

Industry-leading Reliability

VMAC G30 gas powered air compressors are proven to work in extreme cold climates across North America when ordered with an optional, factory-installed cold climate kit. Engines supplied by Honda come with an industry-leading 3-year warranty and VMAC rotary screw air compressors come with the industry’s first Lifetime Limited Warranty. For peace of mind, without the headache.

Components

AIR COMPRESSOR
100% duty cycle VMAC rotary screw, [email protected] psi. Backed by a Lifetime Warranty*

*For more information about VMAC’s Lifetime Warranty Policy, please visit www.vmacair.com/support/warranty/.

ENGINE
GX390 air-cooled 4-stroke OHV; CARB and EPA certified; Honda 3-Year Warranty

WHASP TANK
Patented integrated oil/air separator and air/oil cooler

THROTTLE CONTROL
Controlled by system air pressure, idles up/down automatically with air demand

DRIVE SYSTEM
Gearless, clutchless, auto-tensioned serpentine belt, aluminum belt-guard

UNLOADER
Decreases engine load, lowers sound levels, reduces fuel use and engine wear

BATTERY
ACDelco 12V, 300 CCA, 360 CA

FUEL SUPPLY
Manual choke, Fuel on/off

FUEL TANK
1.6 gallons (6.1 L)

ELECTRONIC KEY SWITCH
Electric start; hour meter

OPTIONAL EQUIPMENT

DUAL 6-GALLON AIR RECEIVER TANKS (A500245 – UNINSTALLED / A520007 – FACTORY INSTALLED)
Base-mounted dual 6-gallon air receiver tanks provide 12-gallons of compressed air storage; includes hoses, fittings, valves, gauge, and tank drain; 150 psi max.

10-GALLON AIR RECEIVER TANK (A300047)
Remote-mounted 10-gallon air receiver tank with mounting feet; includes fittings, valves, gauge and tank drain; 200 psi max; ASME certified.

COLD CLIMATE KIT* (A500044)
Heats up the G30 on the way to the jobsite. Required in below freezing temperatures.
*800W Power Inverter required

800 W POWER INVERTER (A500181)
800 W, 12 V power inverter; required to power the VMAC G30 gas powered air compressor cold climate kit.

REMOTE CONTROL PANEL (A500042)
Remote panel with a 10-foot extension for key switch, hour meter, and choke.

Specifications

  • Air Compressor Output

    30 CFM @ 100 psi (150 psi max)

  • Air Compressor Type

    Belt-driven, 100% duty cycle, VMAC oil-injected rotary screw

  • Engine

    Honda GX390 air cooled 4-stroke OHV with electric start, CARB and EPA certified, Honda approved application.

  • Weight (wet)

    Approximately 205 lbs (93 kg)

  • Dimensions
    • 33.5” (l) x 21.4” (w) x 23.9” (h); 85.1 cm (l) x 54.4 cm (w) x 60.7 cm (h)
    • Mounting Plate: 25.0” (l) x 19.125” (w) / 63.5 cm (l) x 48.6 cm (w)
  • Throttle Control

    2-speed throttle, responds to air demand

  • Battery (included)

    ACDelco 12V, 300 CCA, 360 CA

  • Control System
    • Key switch, choke, hour meter
    • Automatically idles down/up with air demand
    • Unloader decreases engine load, lowers sound levels, reduces fuel use and engine wear
  • Safety System
    • Compressor thermal protection circuit
    • Automatic rapid blow-down valve on tank
    • 200psi pressure relief valve
    • Low engine oil pressure shutoff
  • Decibels (dB) @ 20 feet (6.1 meters)

    81 dB at high idle; 67dB at low idle

  • Fuel Tank Capacity

    1.6 Gallons (6.1 Litres)

  • Air Receiver Tank (Optional; recommended for high duty cycle applications in hot climates)
    • Dual 6-Gallon Air Receiver Tanks – Base-mounted dual 6-gallon air receiver tanks provide 12-gallons of compressed air storage; includes hoses, fittings, valves, gauge, and tank drain; 150 psi max. Available factory installed or uninstalled.
      37″ (l) X 23″ (w) X 10.1″ (h); 94 cm (l) x 58.4 cm (w) x 25.7 cm (h) Weight: 45 lb (20.4 kg)
    • 10-Gallon Air Receiver Tank w/ Mounting Feet – Remote-mounted 10-gallon air receiver tank with mounting feet; includes fittings, valves, gauge, and tank drain; 200 psi max.
      30.0” (l) x 10.0” (d) / 76.2 cm (l) x 25.4 cm (d); 33 lb (15 kg)
  • Warranty

    Two years on all major components; VMAC air-ends are covered by VMAC’s Lifetime Warranty (Limited); Honda engine is covered by Honda’s 3-Year Warranty.
