70 CFM Direct Transmission Mounted Air Compressor
The VMAC DTM 70 CFM air compressor is a direct-transmission mounted PTO driven air compressor.
This system is the best choice for customers who are concerned with saving space and reducing weight on their service trucks. The powerful rotary screw air compressor is ideal for operating small to medium sized air tools with high air demand, like 1” impact wrenches, 60 lb jackhammers, backfill tampers, vertical/horizontal grinders and sanders.
The system is designed for the Ford F250 to F550 Super Duty 6.7L Power Stroke diesel 4×2 and 4×4 work truck with TorqShift™ Automatic Transmission and the RAM 3500 to 5500 chassis cab 6.7L Cummins diesel 4×2 and 4×4 work truck with AISIN Automatic Transmission and PTO prep package (option code LBN).
Truck Mounting Kits
VMAC designs truck mounting kits for the easiest possible installation. Working closely with leading truck manufacturers, VMAC ensures that mounting kits do not affect OEM warranties. Mounting kits available for:
- Ford F-250 to F-550 Power Stroke Diesel
- RAM 3500 to 5500 Chassis Cab Cummins Diesel
Some applications are restricted to specific series and/or models. Please confirm compatible vehicles on VMAC’s Application list.
Applications – Common jobs that use the DTM 70 CFM air compressor:
- Commercial tire services
- Utility servicing
- Heavy equipment repair
- Sign installation
- Oil and gas mobile mechanics
Commonly used air tools – VMAC DTM 70 CFM air compressors can be used for:
- 1” impact wrenches
- 60 lb jackhammers/pavement breakers
- Backfill tampers
- Vertical/horizontal grinders
- OTR tire inflation
- Many other air tools/applications
Up to 70 CFM. 100% of the time.
VMAC DTM70 air compressors use patented rotary screw technology designed to run at 100% duty cycle without stopping, so operators don’t have to wait for their air compressor to fill an air receiver tank. This maximizes tool performance and eliminates downtime.
Decrease truck GVW by up to 260 lb
VMAC DTM70 air compressors reduce truck weight by as much as 260 lb. This is because there is no secondary engine to carry around on your truck. And when compared to other under deck air compressors, at only 150 lb the DTM70 weighs a fraction. Choosing a lightweight air compressor means you’ll be able to add more tools and equipment to your truck, carry more materials, or take advantage of better fuel economy.
VMAC DTM 70 CFM air compressors feature easy to use controls; simply press the on/off button on the digital control box and the system will take care of the rest. The PTO engages, the compressor turns on, and the throttle control automatically idles the truck engine up and down to match air demand. For cold climate operation, there is a heater built into the compressor which automatically warms up on the way to the job so it is ready to work when you are.
VMAC DTM 70 CFM air compressors are easy to install, making installation times up to 50% faster than other under deck air compressor systems. No modifications are required to the RAM or Ford transfer case. No drive shafts are required to cause alignment issues. Traditional under deck air compressors for RAM and Ford Super Duty trucks are extremely heavy, have poor ground clearance, and require additional sourcing of components. VMAC mounting kits are application engineered for RAM and Ford diesel trucks and include all the necessary components.
Free up to 25 cubic feet
VMAC DTM 70 CFM air compressors free up to 25 cubic feet on the truck deck because the air compressor mounts to the transmission, and the rest of the system mounts under the truck. In fact, no components get installed on the truck deck which ensures a clean and professional looking truck, and space for other equipment, tools or materials.
Avoid frustrating breakdowns and maintenance issues
VMAC DTM 70 CFM air compressors are powered by a PTO mounted on the truck’s transmission. Because they don’t have their own engine that needs constant maintenance, less time and money is spent on fixing engine issues and more time is spent on jobs making money.
Work in any climate
VMAC DTM 70 CFM air compressors are proven to work in any extreme climate. With an integrated automatic heater, the compressor is ready to work when you are.
Remotely mounted on the firewall in the engine compartment for easy access for setup/adjustment.
AIR/OIL SEPARATOR TANK
Separates compressor oil from compressed air and mounts safely to the truck’s frame rail.
LCD for on/off controls; observing system status, service reminders, displays error messages and stores error codes
REMOTE HEAVY DUTY AIR FILTER
Remotely installed on truck for easy accessibility. Excludes 2020+ MY Ford Trucks.
VMAC 100% duty cycle rotary screw compressor, driven off an included PTO, directly mounted to the truck’s transmission. Backed by a Lifetime Warranty*
*For more information about VMAC’s Lifetime Warranty Policy, please visit https://www.vmacair.com/support/warranty/
Automated heater integrated into the compressor housing for cold climate operation, heats up the compressor on the way to the job site.
Liquid to liquid cooler integrates into truck’s cooling system and mounts under the radiator.
CHELSEA ® SERIES PTO
CHELSEA ® SERIES PTO Unique patent pending design that provides best in class noise reduction and unprecedented torque capacity of 200-300 Ft. Lb.
Air Compressor Output
Up to 70 CFM* @ 100 psi (175 psi max)
Air Compressor Type
PTO driven, direct transmission mounted, 100% duty cycle, VMAC oil-injected rotary screw
CHELSEA® PTO; electrically actuated, PTO indicator lamp
- CHELSEA® 272 Series (RAM)
- CHELSEA® 249 Series (2011-2019 Ford)
- CHELSEA® 210 Series (2020+ Ford)
Approximately 150 lb (68 kg)
- On/Off function of PTO and compressor
- LCD display
- Service notifications
- Displays error messages and stores error codes/li>
- System temperature
Variable speed; digital throttle control connects to OBD2 CAN bus connector**; adjusts truck engine speed automatically to match air demand
- Automatic compressor heater function
- Compressor over-temp sensor
- Automatic rapid blow-down valve on tank
- 200 psi pressure relief valve
- Truck drive disable circuit on throttle control
- Truck park brake safety shut-off switch on control box
VMAC Lifetime Warranty on VMAC air compressors; two years on all other major components; for details, visit www.vmacair.com/warranty.
*Actual maximum CFM output of the air compressor varies by vehicle application and engine RPM. See application list for details.
**2017+ Model Year Ford & 2019+ Model Year RAM
